EOS IDS-800RS/AD IP DOME ACTIVE DETERRENCE 8MP 4K CAMERA, OUTDOOR – 2.8MM LENS, IP66, AUDIO

(Code: 8041114)

The EOS IDS-800RS/AD  is a 4K / 8MP Active Deterrence outdoor dome camera from the new RS Series by EOSVISION.

Designed to make a difference in modern surveillance systems, it features a 2.8mm fixed lens and built-in audio, combining smart detection, IR night vision, white light illumination, warning lights, and a siren to deliver high-resolution security and active deterrence.

Key Features

• 8.0MP / 4K resolution (3840 × 2160) @ 15fps
• Active Deterrence: White Light, Blue & Red Warning Lights, and Siren
• Smart Motion Detection with Human Detection
• Area Intrusion, Line Crossing, Region Entry & Exit detection
• Automatic switch from B/W IR mode to full-color imaging on events
• 2.8mm fixed lens (78° horizontal FoV)
• Built-in microphone
• H.265 / H.264 dual stream compression
• ONVIF compatible
• IP66 Weatherproof housing for outdoor use
• Simultaneous multi-user access
• P2P Cloud access via QR code using the free EOSVISION smartphone application
• Remote monitoring via PC and mobile devices (Android, iPad, iPhone)
• Recording support via NVR, DVR, CMS, or SD card

Technical Specifications

• Image Sensor: 1/3” CMOS
• Maximum Resolution: 3840 × 2160 (8MP)
• Frame Rate: 15fps
• Minimum Illumination:
  • Color: 0.002 lux @ F1.6 (AGC ON)
  • B/W: 0 lux @ IR ON
• Lens: 2.8 mm fixed
  • Horizontal FoV: 78°
  • Vertical FoV: 42°
  • Diagonal FoV: 92°
• Night Vision / Lighting Range:
  • White Light spotlight up to 20 m
  • IR LED up to 25 m
• Video Compression: H.265 / H.264 dual stream
• Network Protocols: TCP/IP, HTTP, DHCP, DNS, DDNS, RTP/RTSP, SMTP, NTP, P2P
• Interface Protocol: ONVIF
• Smart Detection Functions: Motion Detection (with Human Detection), Area Intrusion, Line Crossing, Region Entry, Region Exit
• Image Enhancement: BLC / HLC / DWDR / DNR
• Web Access: Built-in web server
• Audio: Built-in microphone
• Remote Monitoring: PC, Android, iPad, iPhone
• Recording Options: NVR, DVR, CMS, SD card
• Power Supply: 12 VDC or PoE (IEEE 802.3af)
• Power Consumption: 5W
• Ingress Protection: IP66
• Dimensions: Ø 701 × 152.3 mm
• Weight: 250 g
• Color: White
• Operating Temperature: -35°C to +60°C
• Compatible Mount: JBC-20RS
